Centauro T Star semi-automatisk CNC drejebænk

TECHNICAL SPECIFICATIONS

Max. distance between centres
1600 / 2000 mm

Height of centres over bed
250 mm

Max turning and milling diameter
250 (178) mm

Max Ø permitted by traveling steady
110 (80) mm

Connection for driving and tailstock centre
3 C.M.

Spindle speed
650 – 900 – 1100 – 1300 – 1500 – 1800 – 2200 – 3000 R.P.M

X-Y axis speed
X = 12 / Y = 6 Mt/min

Spindle motor power
3 – 4 (2,2 – 3 KW) HP/CV/PS

Installed power
5,67 Kw

Net weight
800 Kg

OPTIONAL MILLING UNIT

Router head motor power
2 (1,5 KW) HP / CV /PS

Router head collect
ER 25

Programmable router motor speed
0 – 18000 R.P.M

Programmable indexings and pitches via CT/CAD
